PyParsy the HTML parsing library I needed
The problem
When crawling a task of the crawler sometimes is to parse the resulting HTML page for a given request. I see in a lot of crawling tutorials and examples that the BeautifulSoup4 library is suggested. So what developers and up doing is - they write the parser as code. For a one-time crawling -> parsing iteration that will be great, but what if you intend to do this task on regular bases? Will you assume, that the HTML page will never change? If so - then you are good, you can stop reading here.
If you continued reading:
Suppose you are crawling a webpage with changing content (A/B testing is a possible situation) so using the problematic (in my own opinion) approach you will probably do the following:
- Update code
- Test code
- Release a new version
- Deploy the new version
On a big project, this consumes time and your customers are waiting for your fixes so they can consume the crawled data.
A possible solution
Perhaps you have already heard of selectorlib. It is a python parsing library, that defines what you want to extract from a webpage as a YAML file, and then executes the parses from this definition. I find this approach great! You have your YAML definition as a separate file - no business logic changes are required. This solves one part of the problem - you don't need to release and deploy a new version of your application. You could just update the YAML definition.
This solution provides a solution to a problem that was not described yet - no special technical skills are required to manage YAML files. selectorlib provides a Chrome Extension that allows non-technical people to describe what they want to be extracted from a web page.
Selectorlib also integrates with Scrapy. So you are on a good track here.
You have only one problem left - what to do with changes. You will need a different YAML file for different versions of the same page. You end up with a mess of definitions and some complex business logic to run the different versions. Also, some changes are not permanent - again A/B testing. One option would be to ignore them and miss some data points for some time. I don't think that would be acceptable for your clients.
The probably better solution
The trick I used to solve the last problem is to create a new library (somewhat opinionated on what I wanted). It is heavily influenced by selectorlib, but upgrades on it by introducing a list of selectors.
This way you can have one YAML file definition per page and different selectors (for different versions) of the same field. You can run the parser on any version of the web page and expect the same result. You don't need to have complex logic to handle variations.
The structure of the YAML definition files looks like this:
<field_name>:Field name is the top level of the yamlselector:<selector_definition>- The Selector expressionselector_type:<selector_type[XPATH, CSS, REGEX]>- The type of the selector expression only in ofXPATH, CSS, REGEXmultiple:<true/flase>[Optional] true - get all matching results as a list, false - get first matching resultreturn_type:<return_type[STRING, INTEGER, FLOAT, MAP]- Desired return type on ofSTRING, INTEGER, FLOAT or MAPchildren:<list of definitions[Optional] - used forreturn_type: MAP
Example
For the current example, we will be parsing the amazon.de bestseller page. Perhaps the list of products will be different, but the expected result should be similar.
Let's first define our yaml-file:
title:
selector: //div[contains(@class, "_card-title_")]/h1/text()
selector_type: XPATH
return_type: STRING
page:
selector: //ul[contains(@class, "a-pagination")]/li[@class="a-selected"]/a/text()
selector_type: XPATH
return_type: INTEGER
products:
selector: //div[@id="gridItemRoot"]
selector_type: XPATH
multiple: true
return_type: MAP
children:
image:
selector: //img[contains(@class, "a-dynamic-image")]/@src
selector_type: XPATH
return_type: STRING
title:
selector: //a[@class="a-link-normal"]/span/div/text()
selector_type: XPATH
return_type: STRING
price:
selector: //span[contains(@class, "a-color-price")]/span/text()
selector_type: XPATH
return_type: FLOAT
asin:
selector: //div[contains(@class, "sc-uncoverable-faceout")]/@id
selector_type: XPATH
return_type: STRING
reviews_count:
selector: //div[contains(@class, "sc-uncoverable-faceout")]/div/div/a/span/text()
selector_type: XPATH
return_type: INTEGER
Now we are ready to use the file in our python code. But first, you will need to install some dependencies. Assuming you are using poetry for your project:
poetry add pyparsy
poetry add httpx
from pyparsy import Parsy
import httpx
import json
def main():
parser = Parsy('tests/assets/amazon_bestseller_de.yaml')
response = httpx.get("https://www.amazon.de/-/en/gp/bestsellers/ce-de/ref=zg_bs_nav_0")
result = parser.parse(response.text)
print(json.dumps(dict(result), indent=4))
if __name__ == "__main__":
main()
The final result should look like this:
{
"title": "Best Sellers in Electronics & Photo",
"page": 1,
"products": [
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/81ZnAYiX5sL._AC_UL300_SR300,200_.jpg",
"title": "Amazon Basics High Power 1.5V AA Alkaline Batteries, Pack of 48 (Appearance May Vary)",
"price": 19.12,
"asin": "B00MNV8E0C",
"reviews_count": 526202
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71C3lbbeLsL._AC_UL300_SR300,200_.jpg",
"title": "All-new Echo Dot (5th generation, 2022 release) smart speaker with Alexa | Charcoal",
"price": 59.99,
"asin": "B09B8X9RGM",
"reviews_count": 760
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/811OG1FsNFL._AC_UL300_SR300,200_.jpg",
"title": "Fire TV Stick with Alexa Voice Remote (includes TV controls) | HD streaming device",
"price": 39.99,
"asin": "B08C1KN5J2",
"reviews_count": 92504
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/81FGpGF5kaL._AC_UL300_SR300,200_.jpg",
"title": "Amazon Basics AA Industrial Alkaline Batteries, Pack of 40",
"price": 11.78,
"asin": "B07MLFBJG3",
"reviews_count": 72375
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61ymYQD3gaL._AC_UL300_SR300,200_.jpg",
"title": "Fire TV Stick 4K with Alexa Voice Remote (includes TV controls)",
"price": 59.99,
"asin": "B08XW4FDJV",
"reviews_count": 46503
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61UV1sshWKL._AC_UL300_SR300,200_.jpg",
"title": "Varta Lithium Button Cell Battery",
"price": 3.29,
"asin": "B00TYEL11K",
"reviews_count": 62993
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61bLsZejhPL._AC_UL300_SR300,200_.jpg",
"title": "Instax Fujifilm Mini Instant Film, White, 2 x 10 Sheets (20 Sheets)",
"price": 15.95,
"asin": "B0000C73CQ",
"reviews_count": 197326
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71PTROtCLRL._AC_UL300_SR300,200_.jpg",
"title": "2032 20 40 Cell Battery Silver",
"price": 8.99,
"asin": "B07CSZ575S",
"reviews_count": 16096
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/51CDcTTd3-S._AC_UL300_SR300,200_.jpg",
"title": "Apple AirTag, pack of 4",
"price": 119.0,
"asin": "B0935JRJ59",
"reviews_count": 47525
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71yf6yTNWSL._AC_UL300_SR300,200_.jpg",
"title": "All-new Echo Dot (5th generation, 2022 release) smart speaker with clock and Alexa | Cloud Blue",
"price": 69.99,
"asin": "B09B8RVKGW",
"reviews_count": 665
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71EFiZtPjML._AC_UL300_SR300,200_.jpg",
"title": "Duracell Plus C Baby Alkaline Batteries 1.5 V LR14 MN1400 Pack of 4",
"price": 7.13,
"asin": "B093C9FN7W",
"reviews_count": 42466
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/51Z0FcUPmgL._AC_UL300_SR300,200_.jpg",
"title": "ooono traffic alarm: Warns about speed cameras and hazards in road traffic in real time, automatically active after connection to smartphone via Bluetooth, data from Blitzer.de",
"price": 49.95,
"asin": "B07Q619ZKS",
"reviews_count": 26587
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71g8a2BcgRL._AC_UL300_SR300,200_.jpg",
"title": "Fire TV Stick 4K Max streaming device, Wi-Fi 6, Alexa Voice Remote (includes TV controls)",
"price": 64.99,
"asin": "B08MT4MY9J",
"reviews_count": 30523
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/81Tt3+NBcSL._AC_UL300_SR300,200_.jpg",
"title": "KabelDirekt - 2m - 4K HDMI Cable (4K @120Hz & 4K @60Hz - Spectacular Ultra HD Experience - High Speed with Ethernet - HDMI 2.0/1.4, Blu-ray/PS4/PS5/Xbox Series X/Switch - Black",
"price": 7.99,
"asin": "B004BEMD5Q",
"reviews_count": 125724
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61a3VAbtpQL._AC_UL300_SR300,200_.jpg",
"title": "Soundcore Life P2 Bluetooth Headphones, Wireless Earbuds with CVC 8.0 Noise Isolation for a Crystal Clear Sound Profile, 40-hour Battery Life, IPX7 Water Protection Class, for Work and Travel",
"price": 23.99,
"asin": "B07SJR6HL3",
"reviews_count": 115557
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/41qfJN7dLhL._AC_UL300_SR300,200_.jpg",
"title": "Fire TV Stick Lite mit Alexa-Sprachfernbedienung Lite (ohne TV-Steuerungstasten) | HD-Streamingger\u00e4t",
"price": 29.99,
"asin": "B091G3WT74",
"reviews_count": 5601
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/41hX+2Es+vL._AC_UL300_SR300,200_.jpg",
"title": "Echo Dot (3rd Gen) - Smart speaker with Alexa - Charcoal Fabric",
"price": 49.99,
"asin": "B07PHPXHQS",
"reviews_count": 312374
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71nnAxdMtkL._AC_UL300_SR300,200_.jpg",
"title": "Pack of 40 AG13 LR44 1.5 V Alkaline Button Cell Batteries, Mercury-Free (357 / 357A / L1154 / A76 / GPA76)",
"price": 6.99,
"asin": "B079HZ6RQR",
"reviews_count": 10692
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/418AP8pw3KL._AC_UL300_SR300,200_.jpg",
"title": "EarPods with Lightning Connector",
"price": 16.9,
"asin": "B01M1EEPOB",
"reviews_count": 22486
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/715i0StnSlS._AC_UL300_SR300,200_.jpg",
"title": "Amazon Basics High Capacity AA Rechargeable 2400mAh Batteries Pre-Charged Pack of 12",
"price": 21.94,
"asin": "B07NWT6YLD",
"reviews_count": 146981
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61iYFNhtwHL._AC_UL300_SR300,200_.jpg",
"title": "NEW'C tempered glass foil, protective foil for iPhone 11, iPhone XR, 2pcs., free from scratches, fingerprints and oil, 9H hardness, 0.33 mm ultra clear, screen protective foil for iPhone 11, iPhone XR",
"price": 5.99,
"asin": "B07NC8PWDM",
"reviews_count": 76098
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/81Pd4ogDITL._AC_UL300_SR300,200_.jpg",
"title": "LiCB CR2032 3V Lithium Button Cell Batteries CR 2032 Pack of 10",
"price": 6.99,
"asin": "B07P7V9SP7",
"reviews_count": 10781
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61MRw0Bun4L._AC_UL300_SR300,200_.jpg",
"title": "Varta Ready2Use Rechargeable Battery, Pre-Charged AAA Micro Ni-Mh Battery, Pack of 4, 1000 mAh, Rechargeable without Memory Effect, Ready to Use",
"price": 10.22,
"asin": "B000IGW3JC",
"reviews_count": 47147
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61pBvlYVPxL._AC_UL300_SR300,200_.jpg",
"title": "Amazon Basics - high-speed cable, Ultra HD HDMI 2.0, supports 3D formats, with audio return channel, 1.8 m",
"price": 6.99,
"asin": "B014I8SSD0",
"reviews_count": 469788
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71AwNMpA29L._AC_UL300_SR300,200_.jpg",
"title": "Instax Mini 11 Camera",
"price": 79.0,
"asin": "B084S3Y6L1",
"reviews_count": 14441
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/51hsq3bombL._AC_UL300_SR300,200_.jpg",
"title": "Soundcore by Anker Life P2 Mini Bluetooth Headphones, In-Ear Headphones with 10 mm Audio Driver, Intense Bass, EQ, Bluetooth 5.2, 32 Hours Battery, Charging with USB-C, Minimalist Design (Night Black)",
"price": 39.99,
"asin": "B099DP3617",
"reviews_count": 14245
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/61pUgAx+pPL._AC_UL300_SR300,200_.jpg",
"title": "NEW'C Pack of 3 Tempered Protective Glass for iPhone 14, 13, 13 Pro (6.1 inches), Free from Scratches, 9H Hardness, HD Screen Protector, 0.33 mm Ultra Clear, Ultra Resistant",
"price": 5.99,
"asin": "B09F3P3DQD",
"reviews_count": 10136
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71fzcZQlbqS._AC_UL300_SR300,200_.jpg",
"title": "Echo Show 5 | 2nd generation (2021 release), smart display with Alexa and 2 MP camera | Charcoal",
"price": 84.99,
"asin": "B08KH2MTSS",
"reviews_count": 22944
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/81Jz6OogtbL._AC_UL300_SR300,200_.jpg",
"title": "Misxi hard case with glass screen protector compatible with Apple Watch Series 6 / SE / Series 5 / Series 4 44 mm, pack of 2",
"price": 10.99,
"asin": "B07ZRMCRG7",
"reviews_count": 28111
},
{
"image": "https://images-eu.ssl-images-amazon.com/images/I/71gG2vN8FFS._AC_UL300_SR300,200_.jpg",
"title": "Duracell Plus AAA Micro Alkaline Batteries 1.5 V LR03 MN2400 Pack of 12",
"price": 6.99,
"asin": "B093LT2N4Q",
"reviews_count": 20307
}
]
}
Conclusion
You are free to use whatever approach suits you best. I created the pyparsy library for my own needs and my opinion on how to solve the specific problem. If you need a more battle-tested library with a Chrome-Extension - then selectorlib is your best choice. If you share my needs for the library, then you can help by testing the library and submitting issues or pull requests.
